Landsat 4-5 TM L1 & L2
The Landsat Thematic Mapper (TM) sensor was carried onboard Landsats 4 and 5. It provides 6 spectral bands and 1 thermal infrared band. Landsat 4–5 TM Collection 2 includes both Level 1 and Level 2 products, supporting long-term global Earth observation from the early 1980s through 2012.
Landsat 4–5 TM Level 1 products provide radiometrically calibrated and orthorectified Top-of-Atmosphere (TOA) reflectance and brightness temperature data. Landsat 4–5 TM Level 2 products provide atmospherically corrected surface reflectance and surface temperature science products derived from Collection 2 Level 1 inputs.
Basic Facts
| Property | Landsat 4–5 TM Level 1 | Landsat 4–5 TM Level 2 |
|---|---|---|
| Data type | TOA Reflectance and Brightness Temperature | Surface Reflectance and Surface Temperature |
| Spatial resolution | 30 m (thermal band resampled from 120 m) | 30 m (thermal band resampled from 120 m) |
| Sensor | Thematic Mapper (TM) with 6 spectral bands and 1 thermal infrared band | Thematic Mapper (TM) with 6 spectral bands and 1 thermal infrared band |
| Revisit time | 16 days | 16 days |
| Spatial coverage | Whole globe | Whole globe |
| Data availability | Landsat 4: Aug 1982 – Dec 1993 Landsat 5: Mar 1984 – May 2012 | Landsat 4: Aug 1982 – Dec 1993 Landsat 5: Mar 1984 – May 2012 |
| Common usage/purpose | Vegetation monitoring, land use, land cover maps and monitoring of changes | Vegetation monitoring, land use, land cover maps and monitoring of changes |
Accessing Data
To access data you need to send a POST request to our process API. The requested data will be returned as the response to your request. Each POST request can be tailored to get you exactly the data you require. To do this requires setting various parameters which depend on the collection you are querying.
For an overview of all API parameters see the API Reference.
Endpoint Locations
| Service | Notes |
|---|---|
| services-uswest2.sentinel-hub.com/api | Global coverage from July 1982 to May 2012 |
Data type identifiers
Use the following values for input.data.type:
| Dataset | Identifier |
|---|---|
| Landsat 4–5 TM Level 1 | landsat-tm-l1 |
| Landsat 4–5 TM Level 2 | landsat-tm-l2 |
Filtering Options
This chapter explains the input.data.dataFilter object of the process API.
mosaickingOrder
Sets the order of overlapping tiles from which the output result is mosaicked. Note that tiles will in most cases come from the same orbit/acquisition. The tiling is done by USGS for easier distribution.
| Value | Description | Notes |
|---|---|---|
| mostRecent | (default) The pixel will be selected from the most recently acquired tile | |
| leastRecent | similar to mostRecent but in reverse order | |
| leastCC | The pixel is selected from the tile with the lowest cloud coverage | Estimated per tile (~31,000 sq. km); local cloud coverage may differ |
maxCloudCoverage
Sets the upper limit for cloud coverage in percent based on the precomputed cloud coverage estimate for each tile as present in the tile metadata.
tiers
| Value | Description |
|---|---|
| TIER_1 | selects Tier 1 products |
| ALL_TIERS | selected by default. selects Tier 1 and Tier 2 products |
Processing Options
This chapter explains the input.data.processing object of the process API.
| Parameter | Description |
|---|---|
| upsampling | Same as Sentinel-2. |
| downsampling | Same as Sentinel-2. |
Available Bands and Data
Landsat 4–5 TM Level 1 Bands
| Name | Description | Resolution |
|---|---|---|
| B01 | Blue (450–520 nm) | 30 m |
| B02 | Green (520–600 nm) | 30 m |
| B03 | Red (630–690 nm) | 30 m |
| B04 | Near Infrared (760–900 nm) | 30 m |
| B05 | SWIR 1 (1550–1750 nm) | 30 m |
| B06 | Thermal Infrared (10400–12500 nm) | 30 m [1] |
| B07 | SWIR 2 (2080–2350 nm) | 30 m |
| BQA | Quality Assessment band | 30 m |
| QA_RADSAT | Radiometric Saturation and Terrain Occlusion QA Band | 30 m |
| VAA | View Azimuth Angle | 30 m |
| VZA | View Zenith Angle | 30 m |
| SAA | Sun Azimuth Angle | 30 m |
| SZA | Sun Zenith Angle | 30 m |
| dataMask | Data / no-data mask | N/A |
[1]: Thermal band is acquired at 120 m and resampled to 30 m.
Landsat 4–5 TM Level 2 Bands
Includes all Level 1 bands plus surface reflectance and surface temperature–related products:
| Name | Description | Resolution |
|---|---|---|
| B01–B05, B07 | Surface reflectance bands | 30 m |
| B06 | Surface temperature | 30 m |
| ST_QA | Surface Temperature Uncertainty | 30 m |
| ST_TRAD | Thermal surface radiance | 30 m |
| ST_URAD | Upwelled radiance | 30 m |
| ST_DRAD | Downwelled radiance | 30 m |
| ST_ATRAN | Atmospheric transmittance | 30 m |
| ST_EMIS | Emissivity | 30 m |
| ST_EMSD | Emissivity standard deviation | 30 m |
| ST_CDIST | Pixel distance to cloud | 30 m |
| SR_ATMOS_OPACITY | Atmospheric opacity | 30 m |
| SR_CLOUD_QA | Cloud Quality Assessment | 30 m |
| dataMask | Data / no-data mask | N/A |
Units
Both Level 1 and Level 2 units are preserved exactly as defined in the original pages.
- Level 1: TOA Reflectance and Brightness Temperature
- Level 2: Surface Reflectance and Surface Temperature
(See original unit tables for full band-level details.)
Scenes Object
The scenes object stores metadata returned with Processing API responses. Properties may differ depending on mosaicking and product level.
Catalog API Capabilities
To access Landsat 4–5 TM metadata, send a search request to our Catalog API.
Collection identifiers
landsat-tm-l1landsat-tm-l2
Filter extension
eo:cloud_coverlandsat:scene_idlandsat:collection_category
Distinct extension
date
